Seamlessly manages both induction and permanent magnet motors (PMM) with specialized algorithms, supporting a wide range of submersible and surface pumps for maximum operational flexibility.
Complies with IEEE 519 standards, minimizing current and voltage distortions to ensure stable power quality and reduce equipment wear in demanding networks.
Built to operate in Arctic, tropical, desert, and maritime environments (including offshore), with enclosures like NEMA 4/4X for durability and safety.
A premium solution for complex tasks, focusing on minimizing maintenance time with advanced control algorithms and modular design for submersible and surface pumps.
| Power: | Rated output current: 100-2000 A; Supply voltage: 380/480 V, 50/60 Hz (up to 690 V available). |
| Integration: | Modbus RTU (RS-485/232), Ethernet (optional), Wi-Fi; Options include additional I/O connectors, GPRS router, power meter, and customer controller integration via SCADA. |
| Benefits: | Enhances productivity with voltage sag protection and "catch on the fly" mode; UL certified for safety; Reduces ownership costs through 97% efficiency and automatic start modes; Suitable for harsh climates. |
Combines VSD and passive filter in one enclosure for clean sinusoidal output, ideal for networks requiring minimal harmonics and high power quality.
| Power: | Rated output current: 100-1800 A; Supply voltage: 380/480 V, 50/60 Hz; Rectifier pulses: 6/12/18/24. |
| Integration: | Modbus RTU (RS-485/232), Ethernet (optional), Wi-Fi; Options include additional I/O, power supplies (110/220 V), power meter analyzer, and electric lock safety features. |
| Benefits: | Achieves THDi/THDu <5%; Extends equipment life by suppressing distortions; Compliant with IEEE 519 in 30-100% load range; Compact design reduces installation space and costs; Versatile for onshore/offshore use. |
Features phase-shifting autotransformer for operation in independent networks with voltage frequency variations, providing effective harmonic suppression.
| Power: | Rated output current: 100-1800 A; Supply voltage: 380/480 V, 50/60 Hz; Rectifier pulses: 18/24. |
| Integration: | Modbus RTU (RS-485/232), Ethernet (optional), Wi-Fi; Options include power meter, additional power supplies, and ground telemetry unit. |
| Benefits: | Maintains THDi <5% even with unstable frequencies (45-65 Hz); Ideal for generator sets; IEEE 519 compliant in 75-100% load; Eliminates resonance circuits; Robust for wide temperature range (-20°C to +50°C) and offshore applications. |
Cost-effective VSD for basic control of submersible electric pumps with induction or PMM motors, emphasizing reliability in standard operations.
| Power: | Rated output current: 100-2000 A; Supply voltage: 380/480 V, 50/60 Hz. |
| Integration: | Modbus RTU (RS-485/232), optional Ethernet; Basic I/O (expandable); Options include sine filter and GPRS router. |
| Benefits: | Affordable entry-level solution with soft start and overload protection; Extends ESP run life via current optimization; Suitable for various climates; Minimizes downtime with pre-emergency detection. |
Versatile NEMA 4 enclosure designed to integrate third-party VSDs, with built-in protections and filters for custom setups in submersible pump control.
| Power: | Rated output current: Up to 2000 A (depending on integrated drive); Supply voltage: 380/480 V, 50/60 Hz. |
| Integration: | Compatible with Modbus and Ethernet; Includes input switching, output sine filter, and optional passive harmonic filter; Power bay locking system. |
| Benefits: | High protection for reliable operation in harsh conditions; Supports induction/PMM motors; Reduces integration costs; Enhances safety with built-in locks; Ideal for maritime and desert environments. |
Reliable, cost-effective solution with built-in passive harmonic filter for smooth control of asynchronous and PMM motors in harmonic-sensitive environments.
| Power: | Rated output current: 100-1800 A; Supply voltage: 380/480 V, 50/60 Hz; Rectifier pulses: 6/12. |
| Integration: | Modbus RTU (RS-485/232), Ethernet (optional), Wi-Fi; Options include GPRS router, additional I/O connectors, and operating temperature extension to -40°C. |
| Benefits: | Reduces input network load with THDi <5%; Improves overall equipment stability; Economical for IEEE 519 compliance in 70-100% load; Compact NEMA 3R enclosure for reduced logistics costs; Enhances performance under network fluctuations. |
Premium compact solution for harsh climates, with modular design and advanced algorithms for submersible/positive displacement pumps.
| Power: | Rated output current: 100-3000 A; Supply voltage: 380/480 V, 50/60 Hz (up to 690 V available). |
| Integration: | Modbus RTU (RS-485/232), Ethernet (optional); Programmable I/O (analog/digital); Options include capacitor unit for voltage sags, GPRS router, and electrical power meter. |
| Benefits: | Record 97% efficiency for low ownership costs; 20-36% smaller footprint saves space and shipping; NEMA 4/4X for onshore/offshore; Extends ESP life with backspin control; Automatic commissioning and gas lock algorithms. |
Optimized for indoor or sheltered installations, featuring front-only access and modular design for space-constrained facilities like offshore platforms and engine rooms.
| Power: | Rated output current: 100-1800 A; Supply voltage: 380/415/440/480 V, 50/60 Hz; Pulses: 6/12/18. |
| Integration: | Modbus RTU (RS-485/232), Ethernet, Wi-Fi (built-in); UMKA10 controller with 10" touchscreen; Dual-core processor; Options include SIL3 Safe Torque Off and additional I/O. |
| Benefits: | Reduces maintenance costs and downtime with replaceable modules; THD <5% for clean power; SIL3 safety certification; Energy-efficient natural convection cooling; 24/7 global support. |
