E-Cabinet NEMA 3R

Overview
Features
Specification
Photo and video
Downloads

E-Cabinet NEMA 3R Low voltage Industrial drive

One cabinet. One connection. Full control.

Input voltage range

4160 V (-15% … +10%)

Output voltage range

1.47 kV to 5.0 kV (Adjustable)

Power rating range

175 kVA to 1400 kVA

Operating temperature

-20°C to +50°

Key features: E-Cabinet NEMA 3R

Discover the engineering advantages that set the E-Cabinet NEMA 3R apart - and keep your operations running at peak performance.

Single manufacturer ecosystem

Unlike systems that mix components from different vendors, all major components - including the transformers and VSD - are manufactured by Triol. This ensures a single warranty for the entire supply package and simplifies maintenance.

Aluminum power components

To deter theft and reduce costs in high-risk security regions, all power components (windings, chokes, busbars) are made of aluminum rather than precious metals like copper.

IP66

Voltage compartment segregation

The cabinet is divided into specific voltage compartments. Input and output compartments contain only power connections, while low-voltage peripherals are housed separately, ensuring maximum safety for operators during maintenance.

Advanced safety interlocks

The system minimizes electric shock risks by preventing access to the transformer compartment unless the input power is turned off. It includes alarms for unauthorized access.

Wide output voltage versatility

The step-up transformer offers a wide output voltage range from 1.47 kV to 5 kV (with options up to 14 kV) and features a wide tap range with 16 positions, allowing for precise matching to downhole equipment.

High-frequency motor support

The system is designed to support high-speed operations. It handles standard frequencies up to 120 Hz and PMM up to 200 Hz, with customized solutions available for high-frequency motors up to 600 Hz.

from 1470 V to 5000 V

Embedded transformer monitoring

The transformers are equipped with temperature sensors located directly in the windings. This provides real-time thermal data to prevent overheating and extend equipment life, rather than relying solely on ambient air temperature.

Inside the solution: features that drive your results

Look inside the E-Cabinet NEMA 3R to see how smart design becomes real-world performance, efficiency, and uptime.

E-Cabinet NEMA 3R is part of Triol’s Artificial Lift Solutions
